InnoLight 400Gb/s OSFP FR4 2km Transceiver

T-OS4CNT-NBK 400Gb/s OSFP FR4 2km Optical Transceiver

A high-performance, hot-pluggable optical transceiver designed for 400G data center and enterprise networking applications over single-mode fiber.

Key Features

• Form Factor & Compliance: OSFP MSA compliant.

• Reach & Cable Type: Supports up to 2km transmission on Single-Mode Fiber (SMF) with FEC.

• Compliant Standards: 100G Lambda MSA 400G-FR4 Specification.

• Optical Design: 4 CWDM lanes MUX/DEMUX design.

• Data Rate:

  • Aggregate Data Rate: 400 Gbps

  • Per Channel (Optical): 106.25 Gbps (PAM4)

• Electrical Interface: 8x 53.125 Gb/s (400GAUI-8).

• Power Consumption: Maximum of 12W.

• Operating Temperature: 0°C to 70°C (case temperature).

• Optical Connector: Duplex LC.

• Environmental: RoHS compliant.

Applications

• 400G Ethernet switches and routers.

• Data Center Interconnect (DCI).

• Infiniband interconnects.

• Enterprise Networking core and aggregation.

Ordering & Payment Terms:

• Minimum Order Quantity (MOQ): Flexible for small orders
• Shipping: DDP (Delivered Duty Paid) to your destination or shipment via your designated courier account.
• Payment Method: T/T (Bank Transfer)
• Payment Terms:
  30% advance payment, with 70% balance due prior to shipment for bulk orders
