100Gbase-LR1 QSFP28 1310nm 10km SMF Optical Transceiver (SiPh)

No.SiPh 100G QSFP28 LR1 1310nm 10km
  • Hot-pluggable QSFP28 form factor
  • Single channel full-duplex transceiver module
  • Transmission rates of up to 106.25Gbps(100G PAM4)
  • Compliant with QSFP28 MSA and IEEE 802.3cd 100GBASE-LR Ethernet standards
  • Transmission distance up to 1okm over single-mode optical fiber
  • Utilizes silicon optical integration technology
  • Duplex LC optical interface
  • Power consumption less than 4w
  • Commercial operating temperature range
  • Supply voltage 3.3V
  • RoHS compliant (lead-free)
  • 100G QSFP28 DR1 1310nm 500m SiPh Optical Transceiver
  • Description
  • Ordering & Payment Terms
The 100G QSFP28 LR1 optical transceiver module utilizes single-wavelength 100G PAM4 modulation and silicon photonics integration technology. It is widely employed in 100GBASE-LR1 Ethernet links and supports transmission distances of up to 10km over single-mode fiber.
  • Part Number: VQS-SI101LR1C

  • Description: QSFP28 100GBASE-LR Silicon Photonics Optical Transceiver Module

    • Product Type: Silicon Photonics Transceiver

    • Form Factor: QSFP28

    • Application: Data Center

    • Data Rate: 100G

    • Protocol: Ethernet

    • Wavelength: 1310nm

    • Media Type: Single-Mode Fiber (SMF)

    • Reach: 0.5m to 2km

    • Interface: Dual LC
